Telegrammtypen

11.3.1

IO-Link Kommunikation und ID Parameter

Address
hex
Communication Parameter
0x00
0x01
0x02
0x03
0x04
0x05
0x06
Validation Parameter
0x07
0x08
0x09
0x0A
0x0B
0x0C
0x0C
Name Type Data type
Master R/W uint8
Command
Master R/W uint8
cycle time
Min. cycle R uint8
time
Frame R uint8
Capability
IO-Link R uint8
Version ID
Process R uint8
Data In
Prozess R uint8
Data Out
IO-Link R uint8
Vendor ID 1
(MSB)
IO-Link R uint8
Vendor ID 2
(LSB)
Device ID 1 R uint8
(MSB)
Device ID 2 R uint8
Device ID 3 R uint8
(LSB)
Function ID R/W uint8
1 (MSB)
Function ID R/W uint8
2 (LDB)
Attribute Value
volatile
volatile
constant 0x17
constant 0x01
constant 0x10
constant 0x50
constant 0x00
constant 0x00
constant 0x01
constant 0x20
constant 0x01
constant 0x01
static 0x00
static 0x00
Comment
written by
master
written by
master
2.3 ms
ISDU support
IO-Link version
1.0
16bit Pdin, SIO
support
n/a
Pepperl+Fuchs
Inductive
Sensors PMI-
F112 variant 1
not used
