5 Technical Information
PROFIBUS
Offset Meaning
7
Interface Status
B Controller not responds
0
B Not used
1
B Input data not fully coherent yet
2
B Not used
3
B Not used
1...7
8 B HV1 On/Off diagnostic status
7...4
B HV2 On/Off diagnostic status
3...0
9 B HV3 On/Off diagnostic status
7...4
B HV4 On/Off diagnostic status
3...0
10 B HV1 Protect Mode diagnostic status
7...4
B HV2 Protect Mode diagnostic status
3...0
11 B HV3 Protect Mode diagnostic status
7...4
B HV4 Protect Mode diagnostic status
3...0
12 B HV1 Fixed/Step Mode diagnostic status
7...4
B HV2 Fixed/Step Mode diagnostic status
3...0
13 B HV3 Fixed/Step Mode diagnostic status
7...4
B HV4 Fixed/Step Mode diagnostic status
3...0
14 B Serial/Remote/Local/Profibus diagnostic status
7...4
B Not used
3...0
106/114 Agilent 4UHV Ion Pump Controller User Manual / 87-900-137-01 (D)
