Device description – Sounder
Mounting holes for wall installation
1
Acoustic sounder
2
Terminal 2 (J2)
3
Terminal 1 (J1)
4
Tamper switch
5
LEDs
6
Housing screw and cover
7
Jumper (SW1)
8
Terminal 2 (J2) is not provided in an earlier version of the Wired Indoor Sounder
AZSG10020.
Note
Figure 1: Overview of the sounder
Features
7
