Xesar online control unit
E.X.WL.CU0
GND
Supply
Programming
VCC
interface
12V-24V/DC
Relais 1
Relais 2
Input 1
1 2 3
1 2
3
Relais 1 & 2 different function (standard)
Relais 1 & 2 same function
JP2
Networkbus terminated (standard)
Networkbus open
JP3
NETWORKBUS A
JP3
NETWORKBUS B
1 2 3 4
NETWORKBUS A
NETWORKBUS B
Input 2
1 2
1 2
Xesar reader
connector board
Wallreader 1
Wallreader 2
JP1
1 2 3 4
Doorbus terminated (standard)
Doorbus open
JP1
www.evva.com
