PIKO Navigator

6.4.8 Sort the Loco Database

The loco database may be sorted by 3 different criteria:
• Loco address
• picture number
• individually assigned name
When sorting the database by loco names we recommend to name the
locos with the train line first.
For example:
• Taurus BR 182 or
• BR 80
After selecting the preferred sorting function with the process itself is started with .
This may take up to 40 seconds. While sorting the database it must not be turned off.

6.5 Radio transmitter

6.5.1 adio transmitter configuration
The radio transmission configuration option on the PIKO Navigator has been unlocked .
The hitherto inactive menu item, RADIO TRANMITTER CONFIG can now be accessed.

6.5.1.1 Shut down time

The shut down time determines the length of time for which the radio connection to the wireless
receiver is maintained until the navigator automatically logs of when there has been no input. When
shutting down or in the event of a loss of signal, all allocated locomotives are automatically logged
off. The same is true of the wireless receiver is cut off.
