4.1.4 F-ke configuration
This enables you to configure keys 1-8 on the Navigator for momentary or continuous operation.
This means that if numbers 1-8 are not inverted in the display, the keys will continue to function
as before (pressing x 1 correlates with switching on or off x 1 x). By pressing the appropriate key,
this figure will be displayed as inverted (figures 2 and 6). This key is now in Continuous Operation
Mode. As long as the key is held, the function that is programmed on it will be evoked. Conform your
selection using
.
4.1.5 Selecting the locomotive image
You can select the appropriate locomotive symbol from those that are available using the
keys. It addition, it is possible to select the locomotive image directly using the number keys. The
available locomotive symbols can be found in the appendix to this instruction manual in chapter 7.
Confirm your selection with
4.1.6 Naming a locomotive
Here you define your personally preferred locomotive designation, which will be displayed below
the locomotive symbol during vehicle operation. The locomotive name will also be displayed when
using the second locomotive driving function. In that case, the locomotive name appears beneath
the locomotive address.
Use the
and
keys to move between available characters and select the appropriate letters or
desired characters. The following characters are available when designating a personal locomotive
name:
0
1
2
3
K
L
M
N
Once you have selected a character, you move using to the right using the right key of the second
function
.
The ne t character can now be defined in this new location. Continue this process until you have
completed the designated name. The locomotive designation can have up to 10 characters. For
35017-90-7000_2019_p40-76.indd 52
.
4
5
6
7
8
O
P
Q
R
S
9
A
B
C
D
T
U
V
W
X
5 2
and
E
F
G
H
I
Y
Z
-
/
_
05.06.19 10:04
J
