• When the user leaves the detection zone the flow will stop after a fixed period of 2 seconds.
• If the user remains in front of the sensor, the flow will stop after a period of time which can be adjusted from 30 – 100 seconds.
• Shuts-off automatically if misused after the timed flow.
An automatic duty flush can be set to every 12 or 24 hours after the last use, or it can be overridden, depending on the position of the
connecting pins ⑭. This duty flush lasts for 60 seconds, and helps to reduce the risk of Legionella. It prevents water stagnation and bacterial
development in the pipe work.
ADJUSTMENTS:
Shower kits (Fig. F)
• The detection distance can be adjusted from 25 - 60cm using the potentiometer (GAIN) ⑫ located on the electronic unit.
• The time flow can be adjusted from 30 - 100 seconds using the potentiometer (TEMPO) ⑮ located in the electronic unit
(we do not recommend using the minimum or maximum positions.)
MAINTENANCE:
Shower panels
Replacing the solenoid valve
• Shut-off the water supply.
• Unscrew the connecting nuts to remove the faulty solenoid valve.
• Install the new solenoid valve, respecting the direction of the water flow (see arrow engraved on the valve body).
• Replace the filter supplied to protect the solenoid valve from debris.
• Connect the solenoid valve: red cable to the red cross / blue cable to the black cross.
• Restore the water supply and check that the solenoid valve opens and closes.
Changing the battery (Fig. C)
• A red LED will flash to indicate that the battery needs changing:
• Unscrew the screw ④ to change the battery, leaving the washer in place.
• Replace the assembly, carefully tightening it in place.
Shower kits
Replacing the solenoid valve
• Shut-off the water supply.
• Unscrew the connecting nuts to remove the faulty solenoid valve.
• Install the new solenoid valve, respecting the direction of the water flow (see arrow engraved on the valve body).
• Replace the filter supplied to protect the solenoid valve from debris.
• Connect the solenoid valve: red cable to the red cross / blue cable to the black cross.
• Restore the water supply and check that the solenoid valve opens and closes.
MAINTENANCE & CLEANING
• Cleaning chrome: Do not use abrasive, chlorine or acid-based cleaning products. Clean with mild soapy water using a cloth or a sponge.
• Frost protection: Drain the pipes and operate the mixer/tap several times to drain any remaining water.
Product conforms to current European Directives.
After Sales Care and Technical Support:
For UK market only: Tel. 01491 821 821 - email: technical@delabie.co.uk
For all other markets: Tel. +33 (0)3 22 60 22 74 - email: sav@delabie.fr
The installation guide is available on: www.delabie.com
