The BAG MIX CLIMA is a water separator that is to
be used with every boilers, where it separates the water
in the generator and in the plant, when the latter is
characterised by high flow rates that exceed those de-
veloped by the generator itself. It can also be used to
Electrical power supply
Maximum power absorbed by the BAG
Time (opening / closing) for the mix valve
Working range of the sensor (SM)
Working temperature
Electrical protection level wall-mounted installation
Electrical protection level "built-in" installation
Maximum pressure
DESCRIPTION
L
P
H
NET WEIGHT
2
MIX CLIMA
440 mm
160 mm
616 mm
16 Kg

DESCRIPTION OF THE EQUIPMENT

DESCRIPTION OF THE EQUIPMENT DESCRIPTION OF THE EQUIPMENT DESCRIPTION OF THE EQUIPMENT DESCRIPTION OF THE EQUIPMENT
manage mixed low and high temperature heating
systems (radiators / fan coils and radiant panels).
2
The BAG MIX CLIMA unit can be built into the wall,
thereby avoiding any protrusion, or it can be wall-
mounted.
1 Automatic high limit thermostat low tempe-
rature system
2 Manual high limit thermostat low temperatu-
re system
3 Low temperature system NTC sensor
4 Low temperature system pump
5 High temperature system pump
6 Mixing bottle
7 Air vent valve
8 Low temperature system thermometer
9 High temperature system thermometer
10 Mixing valve
11 Electrical connection board
230(±10%)-50
230
140
0 ÷ +50
0 ÷ +90
IP10D
IPX4D
3

DIMENSIONS AND WEIGHT

DIMENSIONS AND WEIGHT DIMENSIONS AND WEIGHT
DIMENSIONS AND WEIGHT DIMENSIONS AND WEIGHT

STRUCTURE

TECHNICAL DATA

TECHNICAL DATA TECHNICAL DATA
TECHNICAL DATA TECHNICAL DATA
V-Hz
W
s
°C
°C
bar
GENERAL
