WARNING
To reduce the risk associated with all applicable hazards:
• Read and follow all safety information contained in the
Installation Instructions and Product Safety Guide prior to
installing, using or servicing the wall mount. Retain these
instructions for future reference.
To reduce the risk associated with choking:
• Do not allow children access to small parts and/or packaging
materials.
To reduce the risk associated with impact:
• The 3M Wall Mount Bracket is required hardware when installing
the 3M Wall Mount onto concrete block walls and stud walls.
• The Wall Mount Bracket must be installed right side out (refer to
installation instructions for details).
• If the 3M Wall Mount Bracket screws can not be driven into wall
studs, do not install the bracket or the 3M system until the wall
is properly reinforced.
• Always provide proper adult supervision when using the wall
mounted projector around children.
• Do not use excessive force in opening or closing the folding arm
of the wall mount.
• Proper installation and servicing must be performed by
experienced installers as outlined in the installation instructions.
• This wall mount is to be used for mounting 3M™ Super Close
Projection System SCP700 Series projectors only. It has not
been tested for other applications.
• Inspect the wall mount periodically to ensure all fasteners remain
tightened and that no damage has occurred. Repair or replace all
issues found prior to further use.
• Do not modify the physical aspects of the wall mount.
• Do not install on a mounting structure or surface that is prone to
vibration, movement or chance of being impacted.
• The wall mounting structure or surface must be capable of
supporting a minimum of 50 lbs vertical load. If not, the wall
must be reinforced per the Installation Instructions prior to
mounting.
• The wall mounting structure or surface must be capable of
supporting a minimum of 300 lbs pull out force. If not, the
wall must be reinforced per the Installation Instructions prior to
mounting.
• Recommended mounting structure or surface is to solid wood
(a minimum of ¾" plywood mounted to a minimum of two
studs) or to solid concrete. If the wall mount is to be installed
on any other structure or surface, use suitable hardware and/or
materials which are commercially available. This hardware and/
or materials must be determined by an experienced installer.
• Do not climb on, hang on or place any added weight other than
the projector on the fixed or folding wall mount.
WARNING
To reduce the risk associated with hazardous voltage:
• Do not re-route the factory installed cables of the folding wall
mount from the bottom of the arm to the bottom of the base
in any way (refer to the Installation Instructions). Pinching or
wearing of the cables must be avoided. If any additional cables
are added to the base, refer to the Installation Instructions.
Inspect cables periodically for damage and repair all issues
found prior to further use.
• Always disconnect the projector power cord from electrical outlet
prior to any servicing.
• Do not install the wall mount in an outdoor or wet environment.
• Do not stuff excess cable lengths under the wall mount cover
once base installation is complete.
To reduce the risk associated with fire:
• Do not install the wall mount near a heater, a fireplace or any
other source of direct heat energy.
To reduce the risk associated with pinch points:
• Keep hands and fingers away from all moving parts to avoid
pinch point injury.
To reduce the risk associated with lifting:
• Always use two experienced installers for installation of the
wall mounts per the Installation Instructions due to weight and
handling concerns.
To reduce the risk associated with impact:
• When installing the Wall Mount Bracket, use only the Long
Anchors included with the bracket.
SAVE THESE INSTRUCTIONS
4
3M ™ Folding Wall Mount SCPFWMSV2
