Installing the Print Server in the Printer

1. Loosen the screws from the cover of the Type B interface.
2. Remove the cover of the Type B interface.
3. Slide the PS107 into the Type B interface.
4. Tighten the knurled screws of the PS107.

Connecting the Print Server to the Network

1. Connect the network cable (RJ-45) to the PS107.

Turn the Printer On

1. Connect the power cord to the printer.
2. Turn the printer on.
In order to verify the installation you can print a status page. To do this, press the
print server's button for a short time.
10
Proceed as follows:
Proceed as follows:
Proceed as follows:
(Establish the power supply)
[en] Quick Installation Guide
