Part 4. Functions and operation:

4.1 Housing Back:

1.
1.
POWER IN: IEC current input socket with fuse holder for F5AL230V fuse.
The assignment of the connection leads is as follows:
Wire
Brown
Blue Neutral conductor
Yellow/Green Protective conductor
The protective conductor must be connected!
IMPORTANT NOTE: Replace the fuse only with a fuse of the same type and with the same values (imprint on the
device). If the fuse is triggered repeatedly, please contact an authorized service center.
2. Power switch:
switches off unipolar, so the mains plug must be disconnected before the housing is opened to avoid electric
shock.
5-pin-socket „Controller":
3.
control (W-2).
4. DMX IN:
3-pin male XLR connector for connecting a DMX control device (e.g., DMX mixer)).
5. DMX Out:
3-pin female XLR connector for forwarding the DMX control signal
6. On-Board Menu:
3.
2.
Pin
Outer conductor
ON: Indicates the power is on. OFF: Indicates that the unit is switched off. The mains switch
This input is used to connect the timer controller (D-800) or radio remote
Displays the operating mode and the value of individual functions.
6.
5.
4.
International
L
N
