4.4 Timer Controller (D-800):

1. 2. 3. 4. 5. 6.
Via their three buttons, the strength of the fog, ejection time and intervals can be set and the functions of the device
can be optimally matched to the requirements of the user.
1. DURATION- Controller: This sets the duration of each fog output.
2. INTERVAL- Controller: This sets the time intervals between the individual fog ejections.
3. OUTPUT- Controller: This sets the amount of fog (0-100%).
4. TIMER- Button: This activates the timer function.
5. CONTINUOUS- Button: This will activate the continuous fog.
6. MANUAL- Button: If the button is pressed, all other settings are deactivated and maximum fog output is
generated.

4.3 Explanations for display and functions:

Set the DMX start-address:
Press the "Function" button until "D512" is displayed. Here you can set the DMX start address. Use the "UP" and
"DOWN" buttons to increase or decrease the value. Note that the machine needs 2 DMX channels. You can adjust
the amount of fog (min - max) and the fan speed (min - max) manually via the display:
