Quick Start - DeFelsko PosiTector UTG Kurzanleitung

The PosiTector UTG powers-up when the center navigation
button is pressed. To preserve battery life, the instrument
powers down after approximately 5 minutes of no activity. All
settings are retained.
1. Remove the protective rubber cap from the probe.
2. Power-up Gage by pressing the center navigation
3. Zero the probe (see pg. 6)
4. Select the correct velocity of sound (see pg. 7)
5. Measure the part (see pg. 3)
Typical Display
Currently
selected
material
Battery
Icon
Introduction
Introduction

Quick Start

Quick Start
The Coupled Symbol appears when the
probe is ultrasonically connected with a
surface.
Steel
Current
Measurement
Measurement
Mode currently set
to multiple-echo
(UTGM probe only)
inch
Unit of
Measurement
1
button.
