DeFelsko PosiTector UTG Kurzanleitung Seite 10

A Scan
A display in which the received pulse amplitude is
represented along y axis and the travel distance
of the ultrasonic pulse is represented along the x
axis.
B Scan
A display in which a cross sectional profile of the
test material is represented.
SE Mode
Switches from multiple-echo
- To detect pits and flaws
- To increase the measurement range
- To obtain thickness measurements in circumstances where
multiple-echo can not
Battery Type
from a choice of "Alkaline", "Lithium" or "NiMH" (Nickel-metal hydride
rechargeable). If NiMH is selected, the instrument will trickle charge the
batteries while connected via USB to a PC or optional AC charger (gage
must be powered ON). The battery state indicator icon is calibrated for the
selected battery type. No damage will occur if the wrong battery type is
selected. DeFelsko recommends eneloop (NiMH) rechargeable batteries.
Statistics
A statistical summary will appear on the display. Remove the last
measurement by pressing the (-) button.
statistics.
HiLo Alarm
Allows the Gage to visibly and audibly alert the user when
measurements exceed user-specified limits.
(Advanced models only)
(Advanced models only)
(UTGM multiple-echo probes only)
Selects the type of batteries used in the instrument
Statistics Mode
Statistics Mode
x
x - Average
↑ - Maximum Value
to single-echo
- Standard Deviation
↓ - Minimum Value
9
mode:
Press (+) to clear
