Product Description

Figure 1 shows the components of the Semi-Rigid Ureteroscope.
Figure 1: The Semi-Rigid Ureteroscope
1. Semi-Rigid Outer tube: contains the working channel, light, and image
fibers
2. Large Working Channel: for introducing flexible instruments or irrigation
3. Small Working Channel: for inserting flexible instruments or irrigation
4. Light Post: for attaching a light cable
5. Eyepiece: for viewing the image
Setting up the Semi-Rigid
Ureteroscope
1. Ensure the ureteroscope is clean and sterile. For cleaning and sterilization
instructions, see the "Cleaning and Maintenance" section of this manual.
2. Attach the ureteroscope to a coupler.
Note If the ureteroscope will be used without a camera or coupler, use eye-
piece for viewing the procedural site.
3. Attach a light cable to the ureteroscope.
• Connect a cable adapter to the light post (a).
• Attach a light cable to the cable adapter
Figure 2: Attaching the light cable to the light post
Outer Tube
Body Light Post
Small Working
(Large Working
Channel
Channel)
Eyepiece
EN-6
