Dynaudio SUB 300/500

Unpacking

To find the suitable position for the SUB 300/500 in your listening room, please read
the chapter "Positioning the subwoofer" on page 15.
Unpacking the subwoofer
1. Unpack the subwoofer on a clean, even and soft area; floor carpeting is very
suitable.
2. The packaging should be opened from the top. Remove all accessories that
come packed with the subwoofer (such as AC power cord and grille). Do not
remove the top part of the protective material.
3. With the protective material still in place but with accessories removed, carefully
tilt the packaging on its side and tilt again to turn it upside-down. Ensure that no
part of the top-cover is obstructing the opening at the top.
4. The outer packaging can now be lifted away from the subwoofer itself. Remove
the protective material that now is on top. Through the polyethylene bag you can
now see the underside of the subwoofer.
5. Open the plastic bag and remove such from around the base of the subwoofer.
6. Again, carefully tilt the subwoofer on its side and again to turn it onto its feet. Note
that the top part of the protective material will now come off easily so ensure that
the subwoofer doesn't drop or slide away in the process.
Check that the contents are complete:
• Subwoofer: The factory-set power requirements (refer to label on rear of
subwoofer) should correspond for the region where the subwoofer was purchased.
Refer also to "Important Safety Instructions" on page 2.
• Front baffle grille.
• AC mains lead. The supplied lead should be suitable for the region where the
subwoofer was purchased.
• Owners Manual.

Grille

The subwoofer can be operated without the grille. However, it is recommended that
the grille is mounted during normal use to help prevent accidental damage or dirt
settling on the cone of the loudspeaker. With subwoofers, the influence of the grille on
the sound is virtually negligible.
NOTICE
• Be careful when mounting the grille not to touch the cone of the loudspeaker itself.
To fit the grille:
Holding it at a 45° angle vertically, align the bottom magnets of the grille with the
bolts on the loudspeaker's baffle.
Gently straighten up the grille until the top magnets of the grille meet the top bolts
of the baffle.
The magnets will click into place. The grille is now attached to the baffle.
To remove the grille:
Removing the grille is the same procedure in reverse.
Before Operation
5
