Before Operation
LFE/SUB Out
1.
Master
Input Preset
Settings
Function
2.
Slave Protect
Processed OUT
INPUT
To Slave
4.
Master
Input Preset
Function Settings
Protect
Slave
Processed OUT
INPUT
To Slave
8

Connecting multiple subwoofers

1. From the processor or receiver's subwoofer output (often marked as "subwoofer
out", "Sub out" or "LFE"), connect a mono RCA-to-RCA or XLR-to-XLR cable to the
INPUT
2. Set the Master subwoofer's
3. From the Master subwoofer's
Store
RCA-to-RCA or XLR-to-XLR cable to the next subwoofer's (Slave) INPUT.
4. Set the Slave subwoofer's
5. Any subsequent Slave subwoofers can be connected in a daisy chain style, going
from the
After all connections are made, connect the supplied mains leads to the
subwoofer's IEC power sockets and a mains outlet.
3. Note
• The
Input Function
the Slave
• When using multiple subwoofers in a Master-Slave setup, it is recommended that
the subwoofers are all the same model.
• If you wish to use multiple subwoofers with full individual control, set the
Store
Function
receiver's subwoofer output, use a Y-connector.

Connecting using the XLR sockets

5.
NOTICE
• DO NOT use XLR and RCA connections in parallel for the same connection.
A balanced signal connection (XLR sockets) provides a connection that is far less
susceptible to cable signal interference compared to an unbalanced connection (RCA
connection). It is for this reason that XLR and balanced connections are used almost
exclusively in critical and professional installations.
Provided your processor or receiver has a XLR symmetric or balanced output for
subwoofer you should consider using the XLR input on the Dynaudio subwoofer. In a
setup with multiple subwoofers you can use the XLR connections between the Master
and Slave subwoofers, even if the connection between the processor or receiver has
been made using the RCA connectors.
Configuring and making connections using XLR is done in the same way as using the
RCA connectors. Please refer to "Connecting a single subwoofer" on page 7 and
"Connecting multiple subwoofers" on page 8.
Dynaudio follows the most usual convention for termination of XLR sockets:
• Pin 1 = ground
• Pin 2 = signal +
• Pin 3 = signal –
Note
• Always ensure that all connections are correct: It may be that the source equipment
follows a different way of terminating the XLR sockets or it may be that the XLR
connection cables themselves do not comply. When in doubt, consult your dealer.
of the first subwoofer in the daisy chain. This is now the Master subwoofer.
Input Function
Processed Out To Slave
Input Function
Processed Out To Slave output to the next Slave subwoofer's INPUT.
switch of each subwoofer operated as a Slave must be set to
position.
switch for all to the Master position. From the Amplifier, processor or
switch to the Master position.
output, connect a mono
switch to the Slave position.
Input
Dynaudio SUB 300/500
