AXIS Q1910/-E/AXIS Q1921/-E Installation Guide
AXIS Q1910-E/AXIS Q1921-E
Part number (P/N) & Serial number (S/N).
The serial number may be required
during the installation.
Protective window
Sunshield adjustment
screw (2x)
Sunshield
Top cover
Thermal network camera
Safety wire tab
Cable holes
Bottom cover screws (4x)
Cable cover
Cable cover screws (4x)
Bottom cover
Gasket
Network cable (route
through wall bracket)
Bracket adapter
Bracket screws (4x)
Bracket adjustment screw
Wall bracket
Example image: AXIS Q1910-E
