Hardware overview

AXIS Q1910/-E/AXIS Q1921/-E
Status indicator LED
Side view
1/4" screw mount for
wall/ceiling stand
Rear view
AXIS Q1910/-E/AXIS Q1921/-E Installation Guide
Power connector
Power indicator LED
Network indicator LED
Button (not used)
LED (not used)
SD card slot
Audio in
Audio out
Network connector
Connector (not used)
Window heater connector
Microphone
(AXIS Q1910/AXIS Q1921
only)
Bottom view
Part number (P/N) & Serial number (S/N).
The serial number may be required
during the installation.
Example image: AXIS Q1910
RS-485/422
connector
I/O
connector
Control
button
