Basic operations
Figure 11: Language window
Press Print Screen to start the OSCAR interface. The Main window opens.
Click Setup - Language. The Language window opens.
In the Language window, select the language and click OK.
3.5.5

Controlling the status flag

The status flag is displayed on the desktop and indicates the name or EID number of the
selected target device or the status of the selected port. You can specify the information
that is displayed in the flag, the flag color, whether the desktop is visible through the
flag, whether the flag is displayed all the time, and where the flag is displayed on the
desktop. Table 4 shows examples of status flags.
Flag
Table 4: OSCAR interface status flags
3.5.5.1

Specifying the status-flag settings

1. Press Print Screen. The Main window opens.
2. Click Setup - Flag.
22
Description
Flag type by name.
Flag indicating that the user has been disconnected from all
systems.
Flag type by EID number.
590-595-609D
