Connecting the Fronius DC Box 60/12 to the In-
verter

Safety

Preparation

1
Connecting
DC Cable
'OUT' to the
Fronius DC
Box 60/12
WARNING! An electrical shock can be fatal. Danger from DC
voltage from solar modules. Make sure that the input and out-
put sides in front of the device are not charged before connec-
ting anything.
1
NOTE! When tightening the hex nut using a flat wrench, use a
second wrench to hold the hex nut * on the threaded bolt securely
Tightening torque 15 Nm
*
1
*
2
4
5
NOTE! Label the DC cable 'OUT' according to its designated
polarity.
13
2
4
3
2
1 1
1 1
1
1 2
Tightening torque 7 Nm
8
7
1 1
1 1
