Perform the following steps to set up your printer. You will need to do this on every computer that
is connected to your network and wants to be able to access the printer.
1. Windows XP Users: Click Windows Start and then Printers and Faxes.
Windows 2000, Me, and 98 Users: Click Windows Start, Settings, and then Printers.
Click Add Printer and the Add Printer Wizard will launch. Click Next.
2.
3. Select Network printer and click Next.
4. Select Connect to a printer on the Internet... and enter the network address listed in Printer
location. Click Next.
Note: The network address that is listed in Printer location must be entered exactly
as it is seen on-screen. The address field is case-sensitive. If the network address is
not entered correctly, the printer will not be located.
5. You will be prompted to choose the brand and model of your printer. You can either select
them from the list or click Have Disk, insert the CD-ROM that came with your printer, and
navigate to your CD-ROM drive to locate the drivers. When you are finished, click Next.
When prompted, select Yes or No to set this printer as your default printer. If prompted, you
6.
can choose to print a test page.
7. You will be shown the information regarding your printer. Click Finish to complete the setup
process.
Step Three: Verify the printer connection
If you look on the Status page of the Web User Interface, your printer status should now be listed
as "Ready". You can verify the printer is working correctly by clicking the Print this page link in
the Help area on the right side of the screen. If this prints correctly, your printer setup is
complete.
If the printer status is listed as "Not Ready", make sure the printer is turned on and that the USB
cable is firmly connected to both the printer and to the Wireless MAXg Router.
If the printer status is still listed as "Not Ready" or if the page did not print correctly, repeat the
setup procedure and make sure you enter all the correct information.
Register your Wireless MAXg Router and Wireless
MAXg USB Adapter
Register your products online at http://www.usr.com/productreg
