Installing the Router and Wireless USB Adapter

Package Contents:
USR5461 Wireless MAXg Router
USR5421 Wireless MAXg USB Adapter
Quick Installation Guide
One (1) Ethernet cable

Prepare for installation

You must have administrator rights on your computer in order to install this product.
You will need to install this Installation CD-ROM on all the PCs on which you plan to install
Wireless MAXg USB Adapters.
To use the Wireless MAXg Adapter, you must be using Windows XP (Service Pack 1 or higher) or
2000 (Service Pack 4 or higher).
For the most updated information, visit: http://www.usr.com/support
You can also refer to the User Guides on the U.S. Robotics Installation CD-ROM for more detailed
information.
Step One: Connect the Wireless MAXg Router
A. Turn off your computer and your cable or DSL modem.
Disconnect the modem's Ethernet cable from your
computer and connect it to the WAN port of the Wireless
MAXg Router.
B. Connect the supplied Ethernet cable to the Network Interface Card of your computer and to
one of the LAN ports of the Wireless MAXg Router.
C. Connect the antenna to the Wireless MAXg Router.
D. Connect the power adapter to the Wireless MAXg Router and to a standard wall power
outlet. Turn on your computer.
Installation CD-ROM which includes User Guides
5VDC power supply
Detachable antenna
1
