Connections

Before making connections:

* First turn off the power of all equipment to be attached.
* Refer to the user manual in regard to this equipment.

Wiring Diagram

LCD monitor
Personal computer
Attaching the Ferrite Core
Attach the Ferrite Core to PC Audio Cable.
Use of the cable without mounting the ferrite core
will result in the occurrence of noise.
1
Open the ferrite core
and clamp it on the PC
Audio cable.
Ferrite Core
01_English
Personal computer
Audio signal
of input device
DVD player
HD laser disk player
2
Close the ferrite core.
9
Equipment with
digital interface
LCD monitor (second monitor)
Mounting Position of Ferrite Core
Attach the Ferrite Core to the end of PC Audio Cable.
Only AUDIO 1 side of monitor.
Ferrite Core
To AUDIO 1 of monitor
English-9
15/10/02, 12:07 pm
VCR
INPUT MUT
To connector of PC
