cables does not interfere any safety equipment nor reduce
safety of the vehicle.
3.
Drill a hole (recommended width of about 10 mm
diameter) behind the license plate frame, right where the
cable will be routed.
4.
After drilling, remove any burs or sharp edges so you do
not damage the cable when pulling it through.
5.
Carefully route the device's cables through the hole.
6.
Assemble the license plate frame to the license plate bore
on the vehicle with suitable screws. Make sure to assemble
the frame so the camera is at the top of the frame.
7.
Place your license plate into the frame.
Note: It is recommended to implement additional safety
measures to secure the license plate in place (eg. by using
screws) to avoid accidental sliding out of the plate.
connection
1.
Connect AV cable plug (6) to the AV signal output of the
license plate frame's camera (7). Next, connect other end of
the AV cable (3) into video input (2) of your vehicle's monitor.
2.
Once the connection is established, connect to power.
Make a permanent connection using a crimp connector
or by soldering etc. Please note the are two different
methods of connecting to power:
• insert power cable plug (10) into camera's power input
(9); next connect the red wire (11) to power (+12 V) eg.
reverse light, and black wire (12) to GND.
• insert power cable plug (10) into camera's power input
(9) and connect the black wire (12) to GND. Next connect
power wire of the AV cable (4) to power (12 V) e.g ACC,
and connect the power wire of the AV cable (5) to red
wire (11) of the power supply cable.
