How to apply and replace sandpaper
Apply the sandpaper (13) to the grinding plate
(9) using the Velcro strip mechanism.
1) Align the sandpaper (13) with the grinding
plate (9) and press it on evenly.
2) Pull the sandpaper (13) off the grinding plate
(9) and replace it with a new one / another one
(B5).
6.4 Dust extraction
WARNING!
Harmful/noxious gases may be
generated when e.g. lead-containing
paint is processed. These gases entail a
risk for the operator and the persons in the
vicinity!
Therefore only use the power tool in
combination with a dust extraction unit,
and protect yourself and other persons in
the working area with additional suitable
personal protective equipment!
When working with this power tool, a lot of dust
is generated. The dust extraction unit is very
useful if you want to keep your workplace clean.
It is possible to combine the extraction system
or a vacuum cleaner with the extraction hose
(11) which is connected to the adapter for dust
extraction.
1) Align the nose at the hose end with the
extraction hose adapter (12) (B3), insert the end
and secure it by turning in a clockwise rotation
(B7).
2) Connect the dust extraction adapter with a
suitable dust extraction unit such as a vacuum
cleaner (B8).
Note: Make sure that the vacuum cleaner is
suitable for being used together with a power
tool.
6.5 Brush edge
24
The grinding head of this power tool is enclosed
by a brush edge (10) which offers the following
two advantages:
a) The brush edge (10) protrudes beyond the
grinding plate (9) and touches the surface to
be processed first. Thus, the grinding plate
is positioned in parallel to the working area
before the insertion tool comes in contact with
the surface which is to be processed. This is to
prevent the formation of sickle-shaped recesses
caused by the grinding disk edge.
b) Furthermore, the brush edge (10) prevents
the generation of excessive dust. Dust
generated during the grinding process is not
transported towards the outside but is removed
by the extraction system.
Make sure before each operation with this
power tool that the brush edge (10) is not
damaged. Have it replaced if there is damage or
wear.
6.6 Connection to the power supply
1) Make sure that the power tool is switched
off. Always switch the on/off switch (3) to off
position before connecting the power tool to
the power supply.
2) Plug the power plug into a correctly installed
socket which complies with the requirements
specified in the technical data.
3) Your power tool is now ready for operation.

7. Operation

7.1 Oscillation rate
Before you start working with the swing speed
to match the appliance. Use a low swing speed
for coarse grinding, increase the oscillation rate
for fine work.
1) Rotate the adjustment wheel (6) to adjust
