Bonum large animal battery-operated clipping machine
Overview
Ite Art. no.
m
1 GT647801 1
2 GT502 1
GT504
3 GT501 1
GT503
GT505 1
4 GT610010 2
5 GT367201 1
6 GT367202 2
7 TA008295 6
8 GT610307 1
9 GT367207 2
10 GT640225 1
11 GT610405 1
12 GT640220 1
13 GT610304 1
14 TA010017 2
15 TA015497 2
16 GT367803 1
17 GT367802 1
18 GT367804 1
19 GT146 1
20 GT640249 1
21 GT641 1
(3INR19/66-1)
22 GT643 (LC40) 1
a – 1
b – 1
c – 1
d – 1
e – 1
f – 1
g – 1
– GT604 1
GT605 1
2
Name
Mounted cutter head housing
Lower cutter plate
Upper cutter plate (for cows)
Upper cutter plate (for horses)
Fixing screw
Oscillator
Guide pin
Oscillating spring leaf
Spring bridge
Fixation screw
Adjusting screw
Knurled nut
Shaft with gear wheel
Oscillating block
Screw, cross-head, M4 x 16
Screw
Right distance part
Left distance part
Mounted oscillator
Torqui precision adjusting aid
On/off button (with LED)
Li-ion battery
Charger
Lubricating point for battery-operated
clipping machine
Tips of the oscillator
Hole in the upper cutter plate
LED, operation indicator
LED, warning indicator
Battery lock
In the UK
Special lubricating oil for cutter head and
cutter plates
Gear grease (tube)
Symbols on product
Caution, general warning symbol
Caution, see documentation supplied with the product
Labeling of electrical and electronic devices according to
directive 2012/19/EU (WEEE), see Disposal
