2. ConneCtIons & Controls

2.1 FRONT PANEL CONNECTIONS

1 rCa Inputs 1/2-CH
Low-level stereo RCA signal input for connection with line-out of the head-unit (sub-out)
2 reMote Control Input port
DIN socket for connection with the separate remote control unit
3 Master/slaVe operatIon Mode sWItCH
Switch to select the operation mode of amplifier. The default setting is MASTER
4 rCa ConneCtIon port For Master/slaVe operatIon
RCA input/output to branch two EA1500FLX amplifiers in master/slave operation mode

2.2 REAR PANEL CONNECTIONS

5 detaCHable poWer Input terMInal
25 mm² direct power input terminal to connect the amplifier to the positive +12V power wire
connected to the car battery and the ground wire connected to the negative or ground wire of
the vehicle
6 Fuse terMInal
Replace defective fuses only with high quality 30 A fuses
7 detaCHable speaKer/reMote output terMInal
Terminal to connect the amplifier to the Automatic (remote) turn-on/turn-off lead of the head
unit and to connect the loudspeaker output terminal to the subwoofer(s)

2.3 REMOTE CONTROL PANEL

8 status leds
Blue "operation" LED signaling correct operation of the amplifier
Red "protection" LED signaling faulty speaker connections or general malfunction of the
amplfier
9 loW pass CrossoVer FreQuenCY Control
Crossover control potentiometer for the frequency adjustment of the 24dB/oct. low-pass filter
10 subsonIC CrossoVer FreQuenCY Control
Crossover control potentiometer for the frequency adjustment of the 24dB/oct. subsonic
high-pass filter
11 Input gaIn Control
Input level gain control potentiometer, allows matching the output voltage of the head-unit's
RCA line-outs to the amplifier input
