Important! The fitting must be installed, flushed
and tested after the valid norms.
Technical Data
Operating pressure:
Recommended operating pressure: 0,1 - 0,5 MPa
Test pressure:
(1 MPa = 10 bars = 147 PSI)
Hot water temperature:
Recommended hot water temp.:
Connections distance:
Connections G ½:
Fault
Insufficient water
Crossflow, hot water being
forced into cold water pipe, or
vice versa, when mixer is closed
Spout temperature does not
correspond with temperature
set
Temperature
regulation
possible
Shower or spout dripping
Instantaneous heater didn't
work with thermostat
max. 1 MPa
1,6 MPa
max. 80° C
65° C
150 mm
cold right -
hot left
Cause
- Supply pressure inadequate
- Filters are dirty
- Shower filter seal dirty
- Backflow preventers dirty or leaking - Clean backflow preventers, ex-
- Thermostat has not been adjusted
- Hot water temperature too low
not
- MTC-thermo cartridge calcified
- Dirt or sedimentation on valve
seat, shut-off unit damaged
- Flow limiter in handshower isn't
removed
- Filters are dirty
- Non return valve hasn't moved back
English
Spare parts (see page 3)
1
handle for thermostat
2
handle
3
escutcheon
4
thermostat cartridge
5
shut off unit with selector
6
hose
7
non return valve
8
filter packing
9
ball S - unions
10 shower holder
11 pipe
12 escutcheon
13 wall flange
14 shower arm
15 filter packing
16 over head shower
17 hand shower
18 safety set
19 filter insert
20 nut
21 mounting set
Remedy
- Check water pressure (If a pump
has been installed check to see if
the pump is working).
- Clean filter in front of the mixer and
on the MTC-thermo cartridge
- Clean filter seal between shower
and hose
change if necessary
- Adjust thermostat
- Increase hot water temperature
to 42 °C to 65 °C
- Exchange MTC-thermo cartridge
- Clean or exchange shut-off unit
- Remove flow limiter
- Clean the filter / exchange filter
- Exchange non return valves
39398000
39397000
96467000
94282000
96509000
28276000
96737000
96922000
94140000
39525000
96770000
96767000
96768000
96769000
94246000
28489000
28514000
95041000
97708000
96157000
96179000
