Owner's manual
NoTeS: Select optimum reception spot before sticking the
antenna.
For best reception, please clean the windshield glass before
sticking the antenna.
1.
Stick the antenna to the windshield.
2.
Insert the antenna plug to the TV input of DVB-T set top box.
3.
Connect the DVB-T set top box to TV with a compatible
cable.
4.
Connect the charger to the antenna and DC 12 V car charger
socket.
TECHNICAL DATA
•
Frequency range: 470-862 MHz (uHF)
•
Gain: max. 28 dB
•
Max. output level: 96 dBµV
•
Impedance: 75 ohm
•
Noise level: ≤ 2 dB
•
Cable length: 5 meters
•
Type: active
•
Power supply: car battery DC 12 V / 50 mA or
TV tuner DC 5 V / 40 mA
7
EN
