Reresentative of models OFAS HL 050 to OFAS HL 070
Key:
Ref Description
1 Display
2 Column A pressure gauge
3 Column B pressure gauge
4 General Purpose Coalescing Filter (Grade AO)
5 High Efficiency Coalescing Filter (Grade AA)
6 General Purpose Dry Particulate Filter (Grade AO)
7 Exhaust silencer
12
OFAS - Oil Free Air System
10
9
8
12
2
13
11
4
5
7
Reresentative of models OFAS HL 075 to OFAS HL 085
Ref Description
8 Dewpoint sensor
9 Control box
10 Column caps
11 Adjustable purge disc
12 Pallet truck lifting points
13 Oil vapour removal stage
