remote controller

main featureS

• By adopting 2.4G auto-connection technology,
scores of copters can be played with at the same
time without any interference.
• Controls the movement functions of upward,
downward, forward,
rightward, left turn, right turn, and 3d flips.
4
Qty (Pc) description
1 screwdriver
1 screws
1 Propeller
functionS of the remote controller
no.
1
2
3
backward, leftward,
4
5
6
7
8
9
10
11
12
Qty (Pc)
1
12
4
function switch function description
Power switch slide the power switch to the "on" position, the remote controller
is powered on; slide the power switch to the "off" position, the
remote controller is powered off.
high / low speed switch use it to change between low and high speed modes.
light switch / headless 1. this is the light switch of the drone. Press it once to turn on the
mode / one key return
switch 2. headless mode on-off button: Press this button for about 2
3. When the drone is flying in headless mode, press the "one key
left control stick throttle control, turn ieft/turn right.
trimmer a this button is inactive.
trimmer B turn the trimmer ieft/right.
trimmer c leftward / rightward flight trimmer.
trimmer d forward/backward flight trimmer.
right control stick forward / backward / leftward /rightward control stick.
Photo / Video recording this button is for the camera / video.
function
3d flip Keep pressing the 3d rolling button and push the forward/backward
and the leftward/rightward control sticks to the edges to perform the
rolling actions, accordingly.
Power indicator if the indicator light keeps blinking slowly: the remote controller is
not activated.
if the indicator light keeps flashing rapidly: the remote controller is
sending out a connection signal to the drone.
if the indicator light stays on without blinking: the remote controller
is ready for controlling the flight.
description
landing gear
Protection guards
charger
light and press it once again to turn off the light.
seconds. the remote control will send out 2
and the words " stick mode" will flash on the lcd screen; then,
the indicator light of the drone will turn from constant "on" to
"flashing", indicating that the drone is in headless mode. Press
this button again for about 2 seconds. the remote control will
send out 2 beep sounds and "stick mode" will stay on, while the
indicator light of the drone turns from flashing to a constant
"on", the drone then exits the headless mode.
return" button, and the drone will fly towards the pilot. Press the
"one key return" button again or operate the forward /backward
control stick, and the drone will exit the one key return function.
Qty (Pc)
2
4
1
beep sounds
