Procedure:
Step 1: The holes for the installation are on the mounting base of the device.
Step 2: Hold the mounting base onto the location where the device is to be installed.
Step 3: Mark the borehole with a pen or a suitable tool.
Step 4: Drill the hole.
Step 5: Hold the mounting base in the desired position and fix it.
Step 6: Adjust the desired inclination-angle on the mounting base and tighten the fixation screws.
Step 7: Position the device onto the mounting base and slide it along the rail until it clicks into place.
OPERATION
After you connected the device to the power supply and switched it on via the power switch on the rear, the
LED FE-41 begins running.
CLEANING AND MAINTENANCE
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device.
Maintenance and service operations are only to be carried out by authorized dealers.
TECHNICAL SPECIFICATIONS
Article:
Power supply:
Power consumption:
Maximum ambient temperature T
Maximum housing temperature T
Min.distance from flammable surfaces:
Min.distance to lighted object:
LED type:
Number of LEDs:
Dimensions (LxWxH):
Weight:
Please note: Every information is subject to change without prior notice. 13.06.2016 ©
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
100-240 V AC, 50/60 Hz
via supplied power unit
6 W
:
45° C
a
:
50° C
C
0.5 m
0.1 m
5mm RGB LEDs
41
230 x 150 x 160 mm
0.5 kg
51918536
11/12
00100258.DOCX, Version 1.0
