9.2.2 Charging scheme

100-240V AC
Action
Left, yellow
power LED
Charging station
connected to mains Illuminated
Insert Handlamp
in switched-off state
Handlamp is Illuminated
charged
Charging finished
Trickle charge Illuminated
12/24V DC
- Charging in progress
- Handlamp is OFF
Power Yes
failure OFF
No
Voltage underrun? Yes
(Only with vehicle flashing
charger)
Emergency light can be deactivated by the factory
No
to ensure that battery is not discharged in the
emergency lighting mode!
Charging
temperature range Yes Illuminated
exceeded?
No
Charging is
continued
36
Charging station Handlamp
Right, status LED Handlamps LEDs
Red: charging
Green: trickle charge
Orange: fault
OFF
Red illumination Power indicator
flashes in acc.
with charging state.
Green illumination Power indicator
00% illuminated
OFF Charging process
is interrupted.
Power indicator is
illuminated in acc.
with battery power.
OFF
Charging process
is interrupted.
Temperature LED
Orange flashing (right) flashing.
Power indicator is
illuminated in acc.
with battery power.

9.2.3 Fixed installation of the charging station

The charging station can be used both as table and wall-mounted unit. The torch is firmly
secured in the charger. A permanent installation at the wall or other suitable objects is
therefore recommended.
For a horizontal wall installation, a mounting bracket is included in the scope of delivery.
When fixing the bracket at the wall, ensure a tight fit. The charger is then plugged onto
OFF
the installed bracket from the top (refer to Fig. 3). The correct fit of the charger is impor-
tant for the stability of the wall assembly. The charger now has to be secured with the
supplied screws (refer to Fig. 3).
When installing the charging station vertically at the wall or on horizontal, level surfaces,
the charger is screwed to the surface. For installation, the charger has four fixing points
(refer to Fig.4).
Up to five charging stations can be connected together - by using the optional connec-
tion cable.

9.2.4 Vehicle charging station

The special vehicle charging station is adjusted to the conventional on-board voltage of
approx. 2 or 24V DC. Installation should be carried out by a competent company and
if used in vehicles, only the horizontal plane is permissible. Refer to Fig. 4. The charging
process is then carried out as described under 9.2.. A complete charging process via
the on-board power supply of a vehicle takes up to 0 hours. The Handlamp can alterna-
tely be charged either in the HV (mains) and in the LV vehicle charging unit.
9.2.4.1 Installation of vehicle charging station.
The charging station must be firmly connected to the vehicle. When fixing the station, the
same fixing points as used for the HVC unit can be used. Refer to 9.2.3.
The fixing points in the vehicle must be approved by the vehicle manufacturer. When
installing the charging station, it is imperative to account for occupant protection. The
charger has to be connected to the electrical vehicle system by an expert and competent
specialised company. The ratings and connection values of the charging station are listed
in the technical data (refer to Section 8 – Technical data).
