Familiarizing Yourself with the Telephone

Starting Up

Connecting the telephone

The telephone can be connected in just a few steps. It is then immediately ready to
be used.

Connecting the receiver and telephone with the coiled cord

At the bottom end of the receiver:
Insert the plug at the short end of the coiled receiver cable in the socket. Pay
attention that the plug engages properly.
On the underside of the telephone:
Insert the plug at the long end of the coiled cable in socket 1. Then press the
receiver cable in the guide.
Underside of
telephone
1
2
Wall socket
(UAE)
22
Telephone line
cable (UAE)
Ringer loud-
speaker
1 2
Long
end
Short end
Coiled receiver
cable
Receiver
