Fig. 4: Connection diagram with MPA III L.
2. Connect the MPA IIIL (3) to a balanced XLR
microphone input with phantom power.
3. Switch the phantom power on. (Refer to the in-
struction manual of the unit to which you
connected your microphone.)
4. If your mixer provides no phantom power:
Connect the M PA I I I L (3) to an optional AKG
phantom power supply (4) (N 62 E, N 66 E, B 18,
B 15) and use an XLR cable (5) (e.g., an optional
MK 9/10 from AKG) to connect the phantom
power supply (4) to the desired balanced input.
Refer to the manual of your bodypack transmitter.
