of these holes leaks water, it indicates that the water seals are worn out. Replace them immediately.
Use a water collector with a wet vacuum to collect cooling water if nearby objects could be damaged by water.
WARNING: Never allow water to enter the motor. A perfectly functioning water collector set up must be
used for any drilling performed at an upward angle.
Instructions for Inserting Adaptors for Convertible models:
Insert fully and then twist clockwise to tighten.
3) SELECTING SPEEDS
CAUTION: Never attempt to change gears on a running machine! Only
adjust when the machine is at rest.
Select the desired gear range by turning the gear selector either clockwise or
counterclockwise into the desired gear. It will usually be necessary to turn the
spindle by hand a little to get it to shift all the way.
DM6P & DMC6P WET DRILLING RECOMMENDED GEARS (reinforced concrete)
BitØ
14mm
Gear
Gear 3
Gear 2
Gear 1
DMC6P DRY DRILLING RECOMMENDED GEARS (soft materials)
BitØ
20mm
Gear
Gear 3
Gear 2
Gear 1
Impossible /
Not recommended
24mm 35mm 92mm
32mm 56mm
Possible
GB
132mm
132mm
Ideal
8
Gear Selector
162mm
162mm 182mm
