AGP DM6P Betriebsanleitung Seite 2

Model
Power Input
Voltage
-1
No Load min
Rated Load Speeds min
Capacity-Wet (Rig-Mounted)
Capacity-Dry
Arbor Thread
Neck Diameter
Dimensions
Net Weight
DM6P Wet Models
9.
1.
DMC6P Wet / Dry Convertible Model
12.
DM6P (Wet)
110-120V: 1700W, 220-240V: 2000W
110-120V~ 50-60Hz , 220-240V~ 50-60Hz (See machine nameplate)
930 / 1520 / 4270
-1
560 / 910 / 2560
162mm (6-1/4")
n/a
1-1/4"UNC & 1/2" BSP
60mm
437mm X 115mm X 289mm
6.4kg (14 Lbs.)
2.
8.
13.
9.
8.
4.
3.
DMC6P (Wet/Dry)
182mm ( 7-1/4")
5.
6.
7.
11.
1. Spindle 1-1/4"UNC & 1/2"BSP
2. Side Handle Lock Screw
3. Gear Selector
4. Tubular Spirit Level
5. Lock Button
6. Trigger Switch
7. Main Handle
8. Water Feed Valve
9. Side Handle Assy.
10. Bull's Eye Level
11. Indicator Light
12. Water Feed Adaptor Head
13. Vacuum Adaptor Head
10.
