Wireless receiver sender status-LED
Red permanently lit: not logged into a wireless sender (free).
Red/green flashes rapidly: Login-mode, the wireless receiver is logging into the wireless sender.
Green permanently lit: The wireless receiver is logged into the wireless sender. The DMX-signal is present
and received.
Red/green flashes slowly: no DMX-signal, the radio link is being held.
The installation procedure of a wireless DMX system depends on the wireless sender. Please refer to
the user manual of the respective device.
Log out one wireless receiver
The projector is logged out via the Control Board, menu Personality - Wireless DMX – Clean WDMX Memo.
Addressing
The Control Board allows you to assign the DMX starting address, which is defined as the first channel from
which the EYE-190 will respond to the controller.
If you set, for example, in the 42 channel mode the address to channel 43, the EYE-190 will use the channel
43 to 84 for control.
Please, be sure that you don't have any overlapping channels in order to control each EYE-190 correctly and
independently from any other fixture on the DMX-chain.
If several EYE-190 are addressed similarly, they will work synchronically.
Press the Up/Down-buttons for setting the desired starting address. Now you can start operating the EYE-
190 via your lighting controller.
Note:
After switching on, the device will automatically detect whether DMX 512 data is received or not. If there is
no data received at the DMX-input, the display will flash.
This situation can occur if:
- the XLR plug (cable with DMX signal from controller) is not connected with the input of the device.
- the wireless receiver is not logged in to the wireless transmitter or no wireless DMX signal is received.
- the controller is switched off or defective, if the cable or connector is defective or the signal wires are swap
in the input connector.

DMX-protocol

Horizontal movement (PAN)
Mode/Channel Decimal
St BA Ex
1 1 1 0 255 00
Vertical movement (TILT)
Mode/Channel
Decimal
St BA Ex
2 2 2 0 255 00
Hexad. Percentage S/F
FF 0% 100%
Hexad. Percentage S/F
FF 0% 100%
F Push slider up in order to move the head horizontally (PAN).
Gradual head adjustment from one end of the slider to the
other (0-255, 128-center).
The head can be stopped at any position you wish.
F Push slider up in order to move the head vertically (TILT).
Gradual head adjustment from one end of the slider to the
other (0-255, 128-center).
The head can be stopped at any position you wish.
