POSSIBLE COMBINATIONS

Fluid Tip
Hardenerd
Carbide
Ø
Steel
mm
SPA-250-XX SPA-254-XX
1.2 12
1.4 14
1.6 16
1.8 18
2.0 20
2.2 22 22
2.8 28B 28
MODEL PART NUMBER
VPR - E70 - 28 C
OPÉRATION
Important : This spray gun is designed for water based application, solvent
is prohibited, it will damage the seal inside the spray gun. To ensure that
this equipment reaches you in first class condition, protective coatings
have been used. Flush the equipment through with water before use.
Connect the air and fluid supply, clean the fluid passage during 3 minutes
and operate trigger piston 10 time at minimum.
SETTING
1. The « ATOM » air valve control the atomizing air pressure
« FAN » reduces the spray pattern size. To increase the
pressure turn clockwise & reverse to reduce turn counter-
clockwise.
2. Fluid flow can be adjusted with the rear ratchet knob, fluid
flow is increased when you turn the knob counter-
clockwise.
Stainless Point
Pu
Steel
SPA-250H-XX SPA-350-XX
12 DE
14 DE
16 DE
18 DE
20 DE
C = Tip/Needle in carbide, H= Tip/Needle Stainless Steel
Tip Ø (2.8 mm)
Air cap number (E70)
Spray gun type
Needle
Hardened
Point
Carbide
Steel
SPA-351-XX SPA-352
DE
DE
DE
DE
DE
22 x
28B x
Adjusting knob
Adjusting knob
6
Air Cap
Point
Stainless E63 E70
Steel
SPA-351-XX SPA-100-XXX
DEH
DEH
DEH
DEH X
DEH X
X
X
E31
X
X
X
X
X
