Features

The FUTECH NEXUS laser offers the interior contractor many great fea-
tures to make work easier and more accurate.
A complete laser, with all needed functions, a bright beam for
high visibility, with very compact dimensions.

Laser Overview {A}

See the diagram of the laser {A} and keypad {B} corresponding to these
callouts.
1) Rotating head
2) Axes indications
3) Plumb or square beam laser beam aperture
4) Rotating laser beam aperture
5) Batteries
6) 5/8"-11 Tripod mount for horizontal setup
7) Sensors for remote control signal

Keypad Overview {B}

The keypad for the FUTECH NEXUS laser has seven buttons and three LED
indicators.
1) On / Off
2) Manual Mode
3) UP
4) DOWN
5) Rotation Mode
6) Scan
7) TILT (Elevation) Alert
8) LED - Manual mode indication
9) LED - Level Status / Battery
10) LED - TILT indication
