Outdoor Unit RXB50/60CV1B
Dimension
Model
RXB50/60CV1B
Dimension
Model
RXB50/60CV1B
L K
A
O
D
A B C D
855 730 328 520
O P Q R
34 23 362 73
L
E F G H
179 46 93 149
S
75
1-2
All dimensions are in mm
C
G H
I
J
I J K L
101 113 603 126
M N
164 15
