Appropriate Usage

• The instrument may only be used under those conditions and for those purposes for
which it was conceived. For this reason, in particular the safety references, the tech-
nical data including environmental conditions and the usage in dry environments
must be followed.
• When modifying or changing the instrument, the operational safety is no longer en-
sured.
• The instrument may only be opened by an authorised service technician, e.g. for fuse
replacement.

Feature Diagram

1. LCD
2. Measurement function selection switch
3. Input socket for measurement ranges
4. Ground connection for all measurement ranges
5. Input socket for current measurement range 200 mA
5
4
4
1
2
3
