b) Programming additional transmitters
Note
In addition to the master transmitter, up to 15 further transmitters (inc.
max. 3 sensors) can be programmed in the VC470-II.
1. Press the programming button of the master transmitter for 3 seconds.
The curtain will "nod" to confirm. Doing so activates the programming mode
of the VC470-II for a new transmitter for 3 minutes.
2. Now press the programming button of a new transmitter which has not yet
been programmed in the VC470-II for 3 seconds.
The curtain will "nod" to confirm.
3. Now press the programming button of the new transmitter for a further 3 sec-
onds.
The curtain will "nod" to confirm.
The new transmitter has been successfully programmed in the receiver.

Checking that the running direction is correct

Press the UP or DOWN button on the transmitter.
The curtain runs in the right direction => Direction switch is OK.
If the curtain runs in the wrong direction, the direction switch must be changed.
Proceed as follows:
1. Pull the mains plug out of the power socket.
2. Turn the direction switch into the opposite position carefully against the
stopper.
3. The running direction is now changed.
4. Re-connect the power and check again.
Direction switch
