Connections

! IMPORTANT
Connection with external air intake
The stove has been designed for hermetic installations.
To make the connection with an external air intake, proceed as follows:
step action
Connect a 50 mm diameter pipe to the combustion air inlet pipe at the back of the stove. Note: the pipe must be no
1
more than 2 m in length.

Chimney connection

The chimney must be sized so as to guarantee the draught declared by the Manufacturer.
Electrical connection
The plug of the stove power cable must be connected only after installation and assembly has been completed
of the device, and must remain accessible after installation.
To perform the electrical connection, proceed as follows:
step action
1 Connect the power cord to the back of the stove.
2 Connect the plug of the power cord to the wall socket.

Electric scheme

Schema elettrico Scheda madre
Scheda OPZIONALE
per gestione
domotica
G2
S3
G4
S2
verde
bianco
S1
G1
G5
LEGENDA:
Sicurezze
T1 - Contatto Sportello fuoco
Use and maintenance manual R-Evolution 11
The connections must be set up by a technician that is qualified and/or authorised by the
Manufacturer.
Schema elettrico KTR AIR
NO
NC
COM
G6
Resistenza
Vers. 01-GER del 05/05/15
Connessione OPZIONALE per
gestione domotica
NC NO C
G5 G5
G6 G6 G6
10 9 8 7 6 5 4 3 2 1
Fase
Neutro
R1
T5
T1
T2
T3
T4
G3
Rev.1 02/02/2018
Page 61
LEGEND:
Safety devices
T1 - Pellet safety
T2 - Vacuum switch
Motors
M1 - Infeed screw gear motor
M2 - Room fan
M3 - Fume exhaust system
M4 - Heat exchanger 1 fan
M5 - Heat exchanger 2 fan
Resistance
R1 - 250watt heaterSonde
Probes
S1 - Fume probe
S2 - External thermostat
S3 - Room probe
S4 - Rear or RRight Probe/
EXT. T.
G2 S5 - RLeft Probe/EXT T.
General
G1 - Flow meter
G2 - Extractor revolution
reading encoder
