• Extra care should be taken while opening the lid when refilling the hot kettle with water.
• Take precautions to avoid scalding with hot water while handling the kettle. Always hold the kettle by the
handle, as the vessel can be hot and may burn you.
• Pour the hot water slowly – excessive tilting may cause the water to flow through the lid – RISK OF
SCALDING!
• Do not use abrasive or chemically aggressive substances to clean the appliance.
• Do not use the unit if it does not operate properly, or if it has been dropped, damaged or exposed to any
liquids. Have the appliance tested and repaired by an authorised service centre.
• Never use the appliance if the supply cable or plug has been damaged; have the defect repaired
immediately by an authorised service centre.
• The appliance is not designed for outdoor use.
• The appliance is intended for household use only, not for commercial use.
• Do not immerse the supply cable, the plug, or the appliance itself in water or any other liquid.
• Never repair the appliance yourself. Instead, contact an authorised service centre for repair.
• This appliance may be used by children 8 years of age and older and by persons with physical or mental
impairments or by inexperienced persons if they are properly supervised or have been informed about
how to use of the product in a safe manner and understand the potential dangers. Children must not play
with the appliance. This appliance may be cleaned by children 8 years of age and older if they are properly
supervised. Keep this appliance and the power cord out of reach of children younger than 8 years of age.
Failure to follow the manufacturer's instructions may lead to refusal of warranty repair.
1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliances by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the appliance.

PRODUCT DESCRIPTION

3 Lid
4 Kettle body
5 Water mark
6 Button to open the lid
7
Carrying handle
8
Supply cable base
Control Panel Description
9 ON/OFF button
10 KEEP WARM button
11 Temperature setting buttons
28
1
4
3
5
2
7
6
9 8
RK 317x
C AUTION
Prior to first use, we recommend boiling the maximum volume of water in the kettle at least 3 times, then
pouring it out. The kettle is then ready for operation. The kettle may only be used with the supplied base.
OPERATING INSTRUCTIONS
1. Take the kettle off the stand (6), press the button (4) to open the lid (1) and fill the kettle with water (up to
the allowed maximum only) Close the lid by pushing onto it.
2. Place the kettle onto the stand (6) – the electrical contacts connect automatically. Thanks to the central
connector design, the kettle can turn around 360° and be put on the base from any side.
3. Connect the base to the mains. The ON/OFF is illuminated in green colour (7) and the 100°C temperature
button is illuminated in blue (flashing).
4. Turn the kettle on by pressing ON/OFF (7). The ON/OFF is illuminated in red colour (7) and the 100°C
temperature button is illuminated in blue (continuously).
5. The kettle will always boil the water to 100°C unless another programme is selected. After reaching the
boiling point, you hear an audible signal and the kettle switches off automatically.
Press the ON/OFF button (7) to end the heating process prematurely.
6. Temperature Selection
Press the button with preset temperature of 70°C, 80°C, 90°C, 100°C (9) to set the required heating temperature.
Confirm your selection by pressing the ON/OFF (7) button. The kettle starts heating the water up to the selected
temperature and the ON/OFF button illuminates in red. The selected temperature button (7) will be illuminated
in blue (continuously). Press the ON/OFF button (7) to end the heating process at any time. Upon reaching the
selected temperature, the kettle turns off automatically and the ON/OFF (7) button returns to the green state.
You can select from the following programmes:
70°C, 80°C, 90°C, 100°C or KEEP WARM (maintain the temperature).
The kettle automatically shuts off after reaching the set temperature (does not apply to the KEEP WARM
programme).
7. KEEP WARM
Press the KEEP WARM button (8).
With this function selected, you can set the temperature to 70°C, 80°C, 90°C. Set the required temperature.
Confirm your selection by pressing the ON/OFF (7) button. The kettle starts operating. In case the kettle is
taken off the stand and put back on within 1 minute, the KEEP WARM function continues to maintain the
preset temperature. You can interrupt the KEEP WARM function by pressing the ON/OFF button (7) and
subsequently turn it off by pressing the KEEP WARM button (8). The kettle turns itself off automatically if not
turned off with the ON/OFF button within 2 hours.
Notice: In case the KEEP WARM function has only been interrupted using the ON/OFF button (7), the kettle
remains in the KEEP WARM mode for 1 minute (even if the kettle is taken off the stand and put back on).
If the ON/OFF button is illuminated in red colour, it means that the water is being heated or kept warm via
the KEEP WARM function.
8. Standby Mode
If no button is pressed on the stand of the kettle for 30 minutes, the kettle turns of automatically and so
does the illumination (the same applies even if the kettle is off the stand).
The kettle can be prepared for operation by pressing the ON/OFF key again.
Note: It is not a sign of a defect when a small amount of water droplets appear on the kettle base (6). It is
a small amount of condensed steam, which deactivates the kettle thermostat.

CLEANING AND MAINTENANCE

WARNING!
Prior to each cleaning operation disconnect the lead-in cable of the appliance from el. socket!
RK 317x
EN
29
