miniland baby digimonitor 3.5" Bedienungsanleitung Seite 21

· Turn the Intercom ON. Keep Push the Channel button (27) at the back for about 3 sec.
Synchronization process is entered. The screen will show up" PRESS CH BUTTON TO
SELECT CHANNEL. PRESS +/- BUTTON TO SET. PRESS MODE BUTTON TO ENTRY."
Use the channel button to choose the required channel. For example, to choose channel 2.
· Once channel 2 is chosen. Use Adjustment button (+) (-) (18) to choose "PAIR". Then press
MODE button to lead the whole Intercom unit into Synchronization situation. The screen will
show up "PAIRING..." meaning it is ready to 'match' with new camera.
· Then Turn ON the NEW Camera. Press and hold the hidden SYNCHRONIZATION button
(10) through the small hole at the back of the Camera using a pin. The Power LED Light will
start flashing, indicating Synchronization process is activated. Remember the Intercom unit
must be ready as above mentioned.
· The Camera unit will make one long beeping sound and the power LED stops flashing,
indicating successful Synchronization, while at the same time the Intercom unit's screen will
show up" PAIRING SUCCEED, CH2 SELECTED. PLEASE PRESS MODE TO
EXIT." So, Press MODE button, you can see image instantly with CH2 displayed on screen
showing which channel you are in.
1
Press CH button to select channel
Press +/‐ button to set
Press MODE button to entry
CH1 Pair Del
CH2 Pair Del
CH3 Pair Del
CH4 Pair Del
EXIT
· For matching more additional camera, select Channel 3 or 4 by pressing Channel button
(27) of the Intercom.
NO Signal!
2
Status
NIL
Paired
NIL
NIL
6
Pairing succeed, CH2 selected
Please Press MODE to exit
10
Press CH button to select channel
Press +/‐ button to set
Press MODE button to entry
CH1
CH2
3
CH3
CH4
3
EXIT
Pairing...
7
11
21
Status
Pair Del NIL
Pair Del Paired
Pair Del NIL
Pair Del NIL
4
8
12
5
9
13
