Beyerdynamic UNITE TP Schnellstartanleitung Seite 24

24
Microphone connector. . . . . . . . . 4-pin mini XLR jack, male
Integrated microphone . . . . . . . . yes
Line-in. . . . . . . . . . . . . . . . . . . . mini jack, 3.5 mm,
Display . . . . . . . . . . . . . . . . . . . monochrome white OLED
Max. number of
open microphones . . . . . . . . . . . 3, individual level control
Battery . . . . . . . . . . . . . . . . . . . lithium-ion battery pack,
Battery monitoring . . . . . . . . . . . Battery status of remaining
Operating time of battery pack . . . > 15 hrs., typ.
Side-tone and
microphone gain. . . . . . . . . . . . . individually adjustable
Bluetooth. . . . . . . . . . . . . . . . . . V4.2
Unite TP – Bodypack Transmitter
(4.5 V bias voltage,
beyerdynamic TG pin
assignment)
max. -6 dBV / 0.5 V RMS
display with high contrast
for each microphone
replaceable by service staff
only
capacity via OLED display
(HFP - Hands-Free-Profile,
A2DP - Audiostreaming)
20k
4
Audio
3
+4.5V
2
1
