Beyerdynamic UNITE TP Schnellstartanleitung Seite 22

22
3. Insert one or more receivers into the charging slots of the
charger to be paired with the transmitter. You can also
connect another receiver to the charger using the USB
port. Remove all receivers that should not be paired. If
there is no receiver in the charging slots, the pairing in-
formation is stored in the charger. This is used for later
pairing without connecting the transmitter to the charger.
4. In order to transfer the pairing information from the
transmitter to the receivers in the slots and to the charger
itself for future pairing, press and hold the "Pair/Reset"
button
status indicator
the pairing is successful. The status indicator will then
remain yellow because the pairing information is now also
stored in the charger.
5. If you want to pair other receivers, remove the transmitter
and all receivers from the charger, set the switch
"Pair & Charge" and insert the unpaired receivers into the
charger. The pairing information is immediately stored in
the unpaired receivers. The pairing information will be
stored immediately in the unpaired receivers. The status
indicator on the receiver will flash yellow rapidly while this
happens.
6. Set the switch
is finished, so that the charger can only be used for
recharging.
7. Switch on the transmitter and one receiver to check that
they have both been paired successfully.
After a few seconds, the status indicator
should light up green and the display
channel name of the transmitter.
Unite TP – Bodypack Transmitter
on the charger for more than 2 seconds. The
will flash yellow for several seconds if
back to "Charge only" when the pairing
on the receiver
should show the
to
