Beyerdynamic UNITE TP Schnellstartanleitung Seite 12

12
µ Microphone connector
You can connect a microphone with a 4-pin mini XLR
connector to the microphone connector (for pin assignment,
please refer to chapter 5 "Technical Specifications").
¸ Line-In, 3-pin jack connector 3.5 mm
You can connect an external player to the jack connector.
¹ USB port, Type C
You can use this connector to charge the integrated battery
pack via a USB power adapter. Furthermore, you can con-
nect the bodypack transmitter to the USB Type C port on a
Unite charger to charge it or to pair it with other devices.
Belt clip
The belt clip allows you to attach the device to clothing such
as a waistband or belt.
Charging contacts
The built-in battery is charged via the charging contacts
when the device is inserted into the charger. Make sure to
insert the device fully into the charging slot so that the
charging contacts have proper contact.
Type plate
The type plate provides information about the name, article
number, certification numbers, hardware version, serial
number and production date.
Unite TP – Bodypack Transmitter
